213201ACA SJ40 T+, SJ45 T+, SJ61 T+, SJ66 T+
46
Section 4 – Inspections Before Operation Visual and daily maintenance inspections
▪
Make sure there is no indication of fuel
leakage from the tank, gauge, hoses, fittings,
pump, and filter.
WARNING
Environmental hazard. Immediately remove
gasoline, diesel fuel, engine oil, and hydraulic
fluid spills and leaks with rags. Discard these
rags in accordance with national, state/provincial/
territorial, and local regulations. Spilled fluids can
damage the environment. When spilled fluids go
into the water (for example, a sewage system,
streams, rivers, or other surface water), they can
kill aquatic life.
4.2-7 Base
Do the inspection that follows:
1
Turret transportation lock
▪
Make sure the turret transportation lock is
unlocked.
▪
Make sure there are no loose or missing parts.
▪
Make sure there is no visible damage.
Axles
▪
Make sure the front
2
and rear
3
drive axles
are correctly attached.
▪
Make sure there are no loose or missing parts.
▪
Make sure all the fittings and hose connections
are tight.
▪
Make sure there is no sign of hydraulic
leakage.
4
Tie rod
▪
Make sure there are no loose or missing parts.
▪
Make sure the tie rod end studs are attached
and tight.
▪
Make sure there is no visible damage.
5
Oscillating cylinders
▪
Make sure the oscillating cylinder assembly
is correctly attached, and there are no visible
spaces.
▪
Make sure there are no loose or missing parts.
▪
Make sure all the fittings and hose connections
are tight.
▪
Make sure there is no sign of hydraulic
leakage.
NOTE
The oscillating axle is locked when the MEWP is
in the elevated travel position or at the elevated
travel speed.
1
3
2
4
5
5
