SJ40 T+, SJ45 T+, SJ61 T+, SJ66 T+ 213201ACA
97
Specifications Section 7 – Technical Diagrams and Specifications
1883AB
Model SJ61 T+ SJ66 T+
Platform Size
Total Platform Length (Outside) 2.44 m (96 in) / 1.83 m (72 in)
Total Platform Depth (Outside) 0.91 m (36 in)
Height
Working 20.62 m (67 ft 8 in) 22.02 m (72 ft 3 in)
Platform Elevated 18.80 m (61 ft 8 in) 20.19 m (66 ft 3 in)
Drive (Maximum) Drivable at all heights
Stowed 2.59 m (8 ft 6 in)
Length Overall with Platform 9.24 m (30 ft 3.75 in) 11.63 m (38 ft 2 in)
Width Outside Standard Tires 2.44 m (8 ft)
Weight With Foam-filled Tires 11,375 kg (25,075 lb) 12,610 kg (27,745 lb)
Platform Rotation 170°
Horizontal Reach 15.62 m (50 ft 3 in) 17.38 m (57 ft 0.25 in)
Wheelbase 2.44 m (8 ft)
Turret Rotation 360°
Turret Tailswing 1.33 m (4 ft 6.5 in)
Maximum Gradeability 50%
Ground Clearance Under Axle 0.36 m (14.25 in)
Turning Radius
Inside
4WD
1.93 m (6 ft 4 in)
Outside 5.05 m (16 ft 7 in )
System Voltage 12 V DC
Battery
Type Lead / Acid
Cold Cranking Amperes 800A
Operating Times
Boom Up 67 - 70 sec
Boom Down 64 - 67 sec
Boom Extend 48 - 58 sec
Boom Retract 40 - 50 sec
Jib Up N/A 18 - 28 sec
Jib Down N/A 10 - 16 sec
Turret Rotate 90 - 110 sec
Platform Rotate 5 - 9 sec
Driving Speeds
Travel Speed
(Lowered Travel Position)
7.2 km/h (4.5 mph)
Travel Speed
(Elevated Travel Position)
0.8 km/h (0.5 mph)
1883AC
Model SJ61 T+ SJ66 T+
Platform Size
Total Platform Length (Outside) 2.44 m (96 in) / 1.83 m (72 in)
Total Platform Depth (Outside) 0.91 m (36 in)
Height
Working 20.62 m (67 ft 8 in) 22.02 m (72 ft 3 in)
Platform Elevated 18.80 m (61 ft 8 in) 20.19 m (66 ft 3 in)
Drive (Maximum) Drivable at all heights
Stowed 2.59 m (8 ft 6 in)
Length Overall with Platform 9.24 m (30 ft 3.75 in) 11.63 m (38 ft 2 in)
Width Outside Standard Tires 2.44 m (8 ft)
Weight With Foam-filled Tires 11,375 kg (25,075 lb) 12,610 kg (27,745 lb)
Platform Rotation 170°
Horizontal Reach 15.62 m (50 ft 3 in) 17.38 m (57 ft 0.25 in)
Wheelbase 2.44 m (8 ft)
Turret Rotation 360°
Turret Tailswing 1.33 m (4 ft 6.5 in)
Maximum Gradeability 50%
Ground Clearance Under Axle 0.36 m (14.25 in)
Turning Radius
Inside
4WD
1.93 m (6 ft 4 in)
Outside 5.05 m (16 ft 7 in )
System Voltage 12 V DC
Battery
Type Lead / Acid
Cold Cranking Amperes 925 A
Operating Times
Boom Up 67 - 70 sec
Boom Down 64 - 67 sec
Boom Extend 48 - 58 sec
Boom Retract 40 - 50 sec
Jib Up N/A 18 - 28 sec
Jib Down N/A 10 - 16 sec
Turret Rotate 90 - 110 sec
Platform Rotate 5 - 9 sec
Driving Speeds
Travel Speed
(Lowered Travel Position)
7.2 km/h (4.5 mph)
Travel Speed
(Elevated Travel Position)
0.8 km/h (0.5 mph)
