Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 173
7.4 Kubota WG2503 Dual Fuel Engine (continued)
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
- 171262 1 • • KIT, Engine - Kubota WG2503
33 164881 1 • • • PUMP, Fuel (not shown)
(For components, refer to Section 8.9)
34 164883 1 • • • MANIFOLD, Fuel pressure (not shown)
(For components, refer to Section 8.9)
35 164886 1 • • • GASKET, Cat 1
36 164885 1 • • • GASKET, Cat 2
37 164880 2 • • • SENSOR, O2
38 164887 1 • • • REGULATOR, LP
39 164888 2 • • • CONNECTOR, Vaporizer
40 164889 1 • • • VALVE, LP lock off
41 170416 1 • • • GASKET, Exhaust
42 136118 1 • • • FILTER, Fuel (not shown)
(For components, refer to Section 8.9)
43 164896 1 • • CONVERTER, Catalytic
- 168706 1 • ENGINE MOUNTS
44 169606 2 • • MOUNT, Engine - rear
45 132028 4 • • MOUNT, Vibration
46 169605 2 • • MOUNT, Engine - front
47 103404 8 • • WASHER, Lock (0.312”)
48 103887 8 • • BOLT, Hex head (0.312”-18 x 0.75” gr 5)
49 125525 4 • • BOLT, Hex head (0.50”-13 x 3.50” gr 5)
50 103996 8 • • WASHER, Flat (0.312”)
51 137241 4 • • WASHER, Flat (0.50” AA)
52 163200 4 • • WASHER, Snubbing
52 702507 4 • • NUT, Hex head nylon lock (0.50”-13)
54 166767 4 • • BOLT, Hex head (M12 x 1.25 x 32 gr 8.8)
55 166821 4 • • BOLT, Hex head (M14 x 1.50 x 35 gr 8.8)
56 116995 4 • • WASHER, Lock (M12)
57 137838 4 • • WASHER, Lock (M14)
- 170434 1 • ENGINE ACCESSORIES
- 168711 1 • • VAPORIZER, WG2503
58 169595 1 • • • BRACKET, Vaporizer
59 121758 4 • • • WASHER, Lock (M6)
60 933834 4 • • • WASHER, Flat (M6)
61 600723 3 • • • BOLT, Hex head (M6 x 1 x 10mm gr 8.8)
62 165927 3 • • • MOUNT, Virbration
63 170399 1 • • • PLATE, Vaporizer
64 800354 1 • • • NUT, Hex head (M6-1.00)
65 143478 1 • • • FITTING, Nipple - brass (0.25” NPT x 2.00”)
66 103164 1 • • • FITTING, 90° elbow (04 NPTF - 04 NPTM)
Parts list continued on the following page.
