Skyjack SJ46AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 175
7.4 Kubota WG2503 Dual Fuel Engine (continued)
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
67 103159 1 • • • FITTING, 45° elbow (06 SAE45M - 04 NPTM)
68 169599 1 • • BRACKET, Catalytic converter
69 148377 2 • • CLAMP, Exhaust pipe (2”)
70 169568 1 • • PIPE, Exhaust
71 170436 1 • • BRACKET, Display
72 170435 1 • • PLATE, Fuse box
73 165930 9” • • HOSE, Vapour (0.75”)
74 800354 2 • • NUT, Hex head (M6-1.00)
75 933834 4 • • WASHER, Flat (M6)
76 600426 2 • • WASHER, Flat (M12)
77 104608 8 • • BOLT, Hex head (M6 x 1 x 16mm gr 9.8)
78 166767 2 • • BOLT, Hex head (M12 x 1.25 x 35mm gr 8.8)
79 600723 3 • • BOLT, Hex head (M6 x 1 x 10mm gr 8.8)
80 116995 2 • • WASHER, Lock (M12)
81 121758 9 • • WASHER, Lock (M6)
82 103870 4 • • BOLT, Hex head (0.375”-16 x 1.50” gr 5)
83 103472 8 • • WASHER, Flat (0.375”)
84 103999 4 • • WASHER, Lock (0.375”)
85 103978 4 • • WASHER, Nut (0.375”-16 gr 5)
86 103320 7 • • CLAMP, Hose (1.00”)
87 102854 2 • • CLAMP, Hose (0.75”)
88 168707 3 • • CLAMP, Loop (1”)
89 170411 1 • • FAN, Kubota (13.5” dia)
90 925229 25” • • HOSE (0.625”)
91 925229 30” • • HOSE (0.625”)
92 163509 23” • • HOSE (300 psi)
93 171120 1 • • SHIELD, Heat
94 169537 1 • • LABEL, Hot surface
95 102287 1 • • CLAMP, U-bolt (1.75” x 2.875”)
96 166739 1 • • DISPLAY, Engine parameter
97 (Ref.) 1 • BELL HOUSING
98 171222 1
• BRACKET, Tail pipe
99 171094 1 • PIPE, Tail
100 102287 2 • CLAMP, U-bolt (1.75” x 2.875”)
101 165678 1 • CABLE ASSEMBLY - Weld (#2/0 3/8” x 33” x 5/16” (03,03))
