112

221491AFA SJ9233 RT, SJ9243 RT, SJ9253 RT, SJ9664 RT

Section 8 – Labels SJ9233 RT, SJ9243 RT, SJ9253 RT & SJ9664 RT labels

Description Label Pictorial

Axldrive™ logo

Talon logo

Hydraulic oil level

Shows the minimum and maximum hydraulic oil level.

HIGH/MAX

LOW/MIN

Front side (continued)
