SJ9233 RT, SJ9243 RT, SJ9253 RT, SJ9664 RT 221491AFA
Visual and daily maintenance inspections Section 4 – Inspections Before Operation
1
2
3
1a
3a
4
4.2-6 Hydraulic and base control side
Do the inspection that follows:
1
Hydraulic tank
▪
Make sure the hydraulic filler cap closes
tightly.
▪
Make sure there is no visible damage or
hydraulic leaks.
▪
Hydraulic oil level:
1. Make sure the platform is fully lowered and
the outriggers are retracted.
2. Do a check on the gauge
1a
on the left
side of the hydraulic oil tank. The hydraulic
oil level must be at or a small distance
above the top mark of the gauge.
2
Main power disconnect switch
▪
Turn the main power disconnect switch to the
off position.
▪
Make sure the switch rotates and stays in the
on and off position.
▪
Make sure the cables are not loose.
3
Base control
▪
Make sure there is no visible damage, and all
the switches are in their off/neutral positions.
▪
Make sure the Skycoded™ display panel
3a
is correctly attached, and there is no visible
damage.
4
Batteries
WARNING
Explosion hazard. Keep flames and sparks away.
Do not smoke near the batteries. Batteries release
explosive gas while you charge them. Charge the
batteries in a well-ventilated area. If you do not
obey, there is a risk of death or serious injury.
WARNING
Corrosion hazard. Do not touch battery acid. Wear
the correct PPE. If the battery acid touches you,
immediately flush the area with cold water and get
medical aid.
1. Do an inspection of the battery case for
damage.
2. Make sure all the battery connections are
tight.
3. If applicable, check the battery fluid levels. If
the plates do not have a minimum 13 mm
(1/2 inch) of solution above them, add
distilled or demineralized water.
WARNING
Only use original or manufacturer-approved parts
and components for the MEWP. If you do not obey,
there is a risk of death, serious injury, or machine
damage.
