87
SJ9233 RT, SJ9243 RT, SJ9253 RT, SJ9664 RT 221491AFA
Floor loading pressure Section 7 – Specifications
Model
Weights Pressures
MEWP Weight
Max Weight per
Wheel/Outrigger** LCP*** OFL***
kg lb kg lb kPa psi kPa psf
SJ9233 RT on
Wheels
Min* 6114 13479 1860 4100 857 124 5.9 124
Max* 7523 16586 2630 5800 930 135 7.1 149
SJ9233 RT on
Outrigger Pads
Min* 6276 13836 1860 4100 498 72 5.9 124
Max* 7523 16586 2630 5800 705 102 7.1 149
SJ9243 RT on
Wheels
Min* 6749 14879 1950 4300 853 124 6.6 137
Max* 7818 17236 2585 5700 920 133 7.4 155
SJ9243 RT on
Outrigger Pads
Min* 6911 15236 1950 4300 522 76 6.6 137
Max* 7818 17236 2585 5700 693 100 7.4 155
SJ9253 RT on
Wheels
Min* 8045 17736 2268 5000 867 126 7.6 159
Max* 8725 19236 2790 6150 971 141 8.3 173
SJ9253 RT on
Outrigger Pads
Min* 8045 17736 2268 5000 609 88 7.6 159
Max* 8725 19236 2790 6150 747 108 8.3 173
SJ9664 RT on
Wheels
Min* 9980 22000 2525 5560 906 131 9.1 190
Max* 10492 23130 3000 6600 1040 151 9.5 200
SJ9664 RT on
Outrigger Pads
Min* 9980 22000 2525 5560 676 98 9.1 190
Max* 10492 23130 3000 6600 800 116 9.5 200
1799AD
Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max: Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel/Outrigger Load is the weight that can be experienced on one wheel/outrigger.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and
LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact
with the floor/tire/outrigger.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole
surface directly underneath the chassis. This has been calculated by dividing the MEWP weight by the
overall floor area occupied by the MEWP (on wheels/outriggers).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above.
Note: The LCP or OFL that an individual surface can withstand varies from structure to structure and is generally
determined by the engineer or architect for that particular structure.
7.6 Floor loading pressure
