75
SJ9233 RT, SJ9243 RT, SJ9253 RT, SJ9664 RT 221491AFA
Use the maintenance support(s) Section 6 – Additional Procedures
6.5-2 Drive and tie-down the MEWP
Before you drive the MEWP:
▪
The ramp or dock capacity must be able to hold
the maximum MEWP weight.
▪
Use side guards (if available) to prevent a fall
from the ramp.
▪
The incline of the ramp must not exceed the
MEWP gradeability. Refer to Section 7.3.
▪
Do a test of the MEWP brakes to make sure they
operate correctly.
▪
Move the inclined-drive/level-drive switch to the
inclined-drive (low speed/high torque) position.
WARNING
When you transport the MEWP, it must be attached
to a truck or trailer deck. Use the available
tie-down points
2
to attach the MEWP. Refer to
Figure 09 If you do not obey, there is a risk of death
or serious injury.
▪
Tie-down the MEWP to the transport vehicle
using the four tie-down points
2
. Refer to
Figure 09.
6.6 Use the maintenance
support(s)
Maintenance support(s)
1
are a mechanism on
the scissor assembly. When they are in the correct
position, they can hold the scissor assembly and an
empty platform.
1
WARNING
Use the maintenance support(s) when you do an
inspection and/or maintenance or repairs in the
confines of the lift mechanism. If you do not use
the support(s), there is a risk of death or serious
injury.
WARNING
Crush hazard. Do not put parts of your body
through the scissor assembly unless the
maintenance support(s) are correctly deployed. If
you do not obey, there is a risk of death or serious
injury.
