221491AFA SJ9233 RT, SJ9243 RT, SJ9253 RT, SJ9664 RT
Section 6 – Additional Procedures Move the MEWP for transport
▪
Remove all personnel, tools, and materials from
the platform.
▪
Attach the rigging to all four lift points
1
. Refer
to Figure 09 and Figure 10.
1
2
Figure 09 Lift and tie-down points
Figure 10 Appropriate method to hoist
NOTE
For the weight of the MEWP, refer to
Section 7.3. Horizontally, the center of gravity
3
is approximately in the middle of the MEWP, front to
back and side to side. Refer to Figure 11. Vertically,
the center of gravity is approximately a small distance
above the chassis.
3
3
Figure 11 Approximate center of gravity
