SJ9233 RT, SJ9243 RT, SJ9253 RT, SJ9664 RT 221491AFA
Specifications Section 7 – Specifications
Model SJ9233 RT SJ9243 RT SJ9253 RT SJ9664 RT
Weight * 6 114 kg (13 479 lb) 6 749 kg (14 879 lb) 8 045 kg (17 736 lb) 9 750 kg (21 495 lb)
Overall Width 2.30 m (7.55’) 2.42 m (7.94')
Overall Length
(Platform Retracted)
4.50 m (14.76’) 4.58 m (15.04')
Overall Length
(Platform Extended - Single)
5.81 m (19.06’) 5.89 m (19.33')
Overall Length
(Platform Extended - Dual)
7.21 m (23.65’) 7.21 m (23.65’)
Platform Size, Inside
(Platform Retracted - Single)
1.92 m (6.30’) x
4.28 m (14.04’)
1.92 m (6.30') x
4.25 m (13.94’)
1.92 m (6.30’) x
4.25 m (13.94’)
1.92 m (6.30’) x
4.38 m (14.38')
Platform Size, Inside
(Platform Retracted - Dual)
1.92 m (6.30’) x
4.28 m (14.04’)
1.92 m (6.30') x
4.25 m (13.94’)
1.92 m (6.30’) x
4.25 m (13.94’)
1.92 m (6.30’) x
4.46 m (14.63')
Platform Size Inside
(Platform Extended - Single)
1.92 m (6.30’) x
5.65 m (18.54’)
1.92 m (6.30’) x
5.65 m (18.54’)
1.92 m (6.30’) x
5.65 m (18.54’)
1.92 m (6.30’) x
5.71 m (18.73’)
Platform Size Inside
(Platform Extended - Dual)
1.92 m (6.30’) x
7.12 m (23.36’)
1.92 m (6.30’) x
7.12 m (23.36’)
1.92 m (6.30’) x
7.12 m (23.36’)
1.92 m (6.30’) x
7.11 m (23.33’)
Height
Working Height 12.06 m (39.57’) 15.11 m (49.57’) 18.15 m (59.55') 21.51 m (70.6')
Platform Elevated Height 10.06 m (33’) 13.11 m (43’) 16.15 m (53’) 19.51 m (64')
Stowed Height (Railings Down) 1.96 m (6.43’) 2.16 m (7.09’) 2.16 m (7.09') 2.78 m (9.13')
Stowed Height (Railings Up) 2.77 m (9.09’) 2.96 m (9.71’) 2.96 m (9.71') 3.60 m (11.80')
Drive Height (Maximum) 10.06 m (33’) 13.11 m (43’) 10.06 m (33') 9.14 m (30')
Standard Operating Times
Raise Time (No Load) 52 s 55 s 80 s 87 s
Lower Time (No Load) 34 s 29 s 39 s 72 s
Raise Time (Rated Load) 52 s 56 s 82 s 87 s
Lower Time (Rated Load) 30 s 29 s 39 s 72 s
Chassis
Travel Speed (Lowered Travel
Position)
5.6 km/h (3.5 mph) 4.8 km/h (3.0 mph)
Travel Speed (Elevated Travel
Position)
≤ 0.80 km/h (≤ 0.5 mph)
Maximum Gradeability 40% 36% 32% 30%
Tires (Solid Rubber) 33 x 12 x 20
Hydraulic Oil
Type
ATF
Bio Oil
Tank Capacity 87 L (23 gal) 117 L (31 gal)
1793AC
* Weights are approximate; refer to MEWP nameplate for specific weight.
7.3 Specifications
