SkyLink EQ SERIES - INSTALL THE DOOR ARMS; Connect Door Arms Together

INSTALL THE DOOR ARMS
1
Connect the Door Arms together
4
Bring two arms together.
Find two pairs of holes
that line up and join 2
arms with bolts and nuts.
Select holes as far apart
as possible to increase
door arm rigidity.
Actual Size
-13-
B2 B8
Sectional Door
Jamb Door
B2x2
B2x2
B8x2
B8x2
