Connect the wires to the “Wall Button” terminals.
Wires are not polarity sensitivity (either wire to
either terminals)
1
Connect the Wires to the Opener
5
C3
1
Route and Secure the wires
4
C3x1
Wire Holder
Route the wire up the wall and across
the ceiling to the opener with wire holders
INSTALL THE WALL BUTTON
Up
Down
Learn/set
Wall Button
Safety Beam
Backup Battery
Power Travel Learn
-15-
