01/10/2016
19/26
E_MH_Installation_instruction_Skycom_Skymax_CE
Settings (factory setting: marked in bold)
By means of jumpers and dip switches it is possible to enable/disable several functions.
Factory settings are for 1 opening system Skymax CE with 1 Skycom Skymax control.
Text on board Factory
mounted
Mounted / ON function Dismounted / OFF function
DIP 1 Conf. Fireswitch OFF
Fire switch active from 500-3KΩ
Fire switch active from 0-3KΩ
DIP 2 Failsafe OFF Line error on re switch or detector puts
the control in alarm
Normal mode
DIP 3 Temp. Detekt OFF Line error on motor line (upper resistor
area) = alarm
Normal mode
DIP 4 Service T OFF Active Inactive
DIP 5 Snitch OFF LED’s “remember” errors (line errors,
AC/Batt. error, bus error). The LED’s
can only be switched off/reset again by
setting dip switch off
Normal mode
DIP 6 Fail Relay OFF Failure relay works as indication that
skylight is open
Normal mode (works as failure relay)
DIP 7 Week open OFF Weekly open (2 sec.) /close
(5 sec.) cycle activated
Weekly open/close not activated
DIP 8 AG Mode special ON Priority “close” button enabled +
10 s comfort pulse
Normal mode + 6 s comfort pulse
DIP 9 Sprinkler OFF Motor output closes by active detector
(opens by activating the re switch) or
internal T-detection
Normal mode - motor output opens
by ative detectors or re switches
DIP 10 Bus comfort ON The control reacts on comfort signal
via bus activity
The control does not react on comfort
signals via bus activity //
Always reaction
on weather signal and failures via bus activity and
own comfort signal
DIP 11 Bus re ON The control reacts on alarm signal
via bus activity
The control does not react on alarm
signal via bus activity
//Always reaction on weather signal and failures
via bus activity and own alarm signal (detector or
fire switch)
DIP 12 BR Mode special OFF comf. active at all failures
Alarm only as long as input is activated
Normal mode
J1 ON Buzzer functional Buzzer off
J2 Mot Mon act. yes Known actuator: line monitoring
(motor) with 2-wired motor connexion No line monitoring
Ext Li Mon act. no Unknown actuator: line monitoring
with 3-wired motor connexion.
J3
(motor)
1 - 2 - 3 - 4 Pos. 1 Set up according to number of
27KΩ resistors on actuator exit
No line monitoring
(J3 and J2 not connected)
J4(Bus) Start term.
+
No
First control unit in the bus
network
which is also master
See section concerning connection of
controls units in bus connection, page
14
J5(Bus) Master No
J6(Bus) Slave No Middle and last control unit in the bus
network
J7(Bus) End term. No Last control unit in the bus network
J9 * FOIL Ye s Line monitoring of keypad foil Line error ashes
J11 * BatSup -> Ø 23 No Battery backup of terminal 23 Terminal 23 only AC supplied
Others: Reset time = 180 sec. closing // Cut-off motor output and loading after 360 sec. // Comfort variable (potentiometer): 1-60
sec.
* As from new edition (March 2015)
ENGLISH
