E_MH_Installation_instruction_Skycom_Skymax_CE 01/10/2016
26/26
Power supply : 230V AC / max. 1,2A
Operating conditions : - 5 °C to + 60 °C / Humidity max 90%, non- condensing/
internal use without aggressive vapers & gases
Protection degree : IP54
Colour : RAL 9003 (white)
Dimensions WxHxD : 286x238x113 mm
Weight incl. batteries : 7,5 kg
Autonomy battery : Min. 72 hours
Internal T-sensor : Alarm generated at 75°C
Max. load : 24V / 5A (Fuse F1: 8A Fast acting)
Motor output : 1 pc. (terminals 6mm²) – line detection: 1-4 lines
Fire switches & zones * : 1 re zone, 8 - 10 pcs. external re switches,
depending on the load
Comfort zones * : 1 comfort zone - unlimited number of switches
Smoke- and heat detectors : 1 input - max. 20 pcs. detectors per control
Priority switch : 1 input for an external Priority switch
Wind- and rain sensor * : Input for close all
Connection of control units : Bus connection integrates most functions -
Max. 35 controls in the same bus connection
Alarm output * : Potential free SPDT change over max. 48V 0,5A
Fault output * : Potential free SPDT change over max. 48V 0,5A
Supply output * : 24VDC 0,5A at 230VAC operation
Line surveillance on : Motor lines, re switches,smoke detector Priority switch,
and communication bus
Visual indication (LED) : OK, AC fault, Low battery, Line fault, Alarm, comfort open
*
not present on Slave
Manufacturer:
AG.PLASTICS, Spinnerijstraat 100, B-8230 Harelbeke, Belgium, website: www.skylux.be
SHE service: Tel.: +32 (0) 56 24 81 05
I
e-mail: service@skylux.be
Skycom Skymax CE Control:
Skycom CE Manual:
Version Production date Description
01 June 2014 First release
02 March 2015 New PCB with low consumption, keypad, J9, J11, T-sensor, ...
03 October 2016 EMC update: ferrite + GND 22-G+SW
Version Release date Description
01 December 2015 First release
02 October 2016 New wind and rain detector AWR-24/250 added
SHE survey added + EMC update
TECHNICAL SPECIFICATIONS
CONTROL FOR 1 FIRE ZONE AND 1 COMFORT ZONE
REVISIONS
