E_MH_Installation_instruction_Skycom_Skymax_CE 01/10/2016
6/26
The Skycom CE controls are intended for opening of skylights, smoke hatches, ... for Smoke and Heat Extraction (SHE)
and comfort ventilation of 1 re zone.
The Skycom Skymax CE control is typically used to command 1 Skymax smoke hatch in a staircase.
The Skycom Skymax control has the following operation possibilities (upon accessories):
Operation for Smoke and Heat Extraction (control in Alarm-status):
1. Automatically activated: by smoke or heat detectors. Each control has also an internal T-sensor which generates
alarm at 75°C.
2. Activated by passer-by: on ‘break-glass’ re-switches
3. Operation by remen: possibility for priority open and close on the priority switch for remen
Operation for comfort ventilation:
Activated by opening-closing switches (push buttons) or by weekly timer, room thermostat,
outdoor weather sensor.
The operation status (OK / alarm / fault / smoke hatch open) is indicated by Led’s and is also available on outputs for con-
nection with other systems (AFA-systems, Air-gates, buzzer, ...) in the building.
We advise to consult your re department to choose the best installation place fort all SHE accessories. You’ll nd an
example on page 7. Generally, install the control panel for the remen (prior switch) at a visible place and easy to be
reached, on the access road of the remen with the bottom at 1,35 - 1,45 m above the oor in the entrance hall of the
(main) building.
The Skycom Skymax CE Slave control must be installed as close as possible (max. 5 m) to the opening system, i.e. at
the ceiling of the building or against the roof opening.
The control unit weights 7,5 kg and must be installed on a stable underground. The mounting holes for wall mounting
are placed on the metal plate underneath the plastic lid.
Foresee (at least) a separate 230V power circuit with its own automatic circuit breaker for each re zone. Don’t connect
other devices to this circuit!
It is sometimes required to supply the control unit with a 230V circuit with separate earth leakage circuit breaker and that
a circuit breaker is installed on the actuator line.
GENERAL DESCRIPTION
INSTALLATION
