SAFETY & WARNINGS
1. The SHE-control must be installed or serviced by a qualied person, authorised for working at electrical Smoke and Heat
Extraction systems. The control and accessories must be installed according to the local norms.
2. Service!
Before installation or service disconnect electrical power and remove the indicated terminal of the battery. Afterwards
reconnect the terminal, mount the housing before switching on electrical power. Now you can test the complete installation.
3. Service of opening system:
Before servicing the opening system, make sure the opening system can not start to move unexpectedly. Therefore
remove the 8 A glass-fuse before starting service at the opening system. This disables the main supply and the battery
supply of the opening system.
4. Batteries:
- To avoid explosion danger follow these safety rules:
• Never short circuit a battery.
• Do not use external chargers. Explosive gasses can be released.
• Always handle batteries with care as they contain strong acids.
- Avoid to store controls with batteries for a long time. Batteries which are not used must be recharged (unload & load)
every 3 months to slow down the capacity loss.
- Don’t discharge batteries to deep as they might be damaged.
- There is no guarantee on batteries.
5. Guarantee expires:
• If controls or cables (especially motor cable) are wrongly dimensioned;
• If non-original parts are used. Use only original parts delivered by AG.Plastics. Especially take care to use a
control which is suitable for the SHE opening system;
• If opening systems are not connected according the installation instructions. Most opening systems must be
connected through a limit switch. Please consult thoroughly the electric scheme of the appropriate SHE system
before connection.
6. Next to the installation of a SHE system, make sure you take all necessary steps to be able to proceed to a smooth
evacuation. Foresee several escape routes, make sure the remen can reach easily the re place. See to the possibility
of a quick signal to the re department in case of re by a full re detection system,… Consult your architect, constructor
and re-department.
7. The SHE-system needs mains voltage. In case of power failure, the system will continue to operate on its batteries in a
limited period of time (min 72 h).
8. Mains power failure g putting out of service:
If the mains voltage is switched off for a longer period of time (> 1 day), disconnect the indicated pin of the battery and
insulate the wire end. Otherwise, you will risk that the batteries discharge and will be damaged.
9. There is a possibility that the smoke does not reach the detector due to chimney effects through walls, shafts, roofs. Also
behind a closed door or at another oorlevel may the smoke not be detected. A detector may be less sensitive to certain
types of re so that the signal is given in a later phase. Make sure to install sufficient detectors at right places.
10. It may occur that the opening system is not correctly operated due to a panic situation in case of re.
11. The SHE-control does not protect people or objects from being stuck when the actuators are activated. This must be
done externally.
12. The manufacturer is not responsible for the loss of a life or materials caused by re, smoke, wind, rain, … even when
the rain- and wind detector is connected. Make sure no damage (wind, rain, …) can be caused during uncontrolled open-
ing of the system.
13. The SHE-control and accessories must not be used as connector box for cables ! Use an external connector box.
14. The wiring for the accessories (re push buttons, detectors, prior key contact, ...) must be at least 1 m off other current
wires (not in the same wire drain) to prevent from interference.
15. We reserve the right to modify this manual or the products without prior notice. You can always check the newest ver-
sion on www.agplastics.com.
16. The responsible person must keep this manual, if possible near the control unit.
17. In particular cases due to fall-through safety, it’s forbidden to open the smoke hatches more than 30 cm for ventilation.
ENGLISH
