h. Flex Positioning. To place the table top in
a flex position from horizontal, press the FLEX
button (figure 3-10). To return the table top to a
horizontal position or into a reflex position, press
the RETURN or REFLEX button.
Figure 3-10. Flex/Reflex Positioning
i. Return To Level (6001KR & 6001KRB only).
To return the table top to a level position, press the
RETURN button (figure 3-11).
NOTE
Elevation and brake system functions
are not affected by the return to level
function.
f. Elevation. To raise table top, press the
TABLE UP button (figure 3-8). The table will lift a
patient weight of 500 pounds up to a maximum
height of 43". To lower the table top, press the
TABLE DOWN button. The table top will go down
to a minimum height of 28".
Figure 3-11. Return To Level
Figure 3-9. Leg Section Positioning (6001)
IMPORTANT
The Leg section may hit the table base
or the floor if both the leg and elevation
systems are placed in their full down
position.
Figure 3-8. Elevation Function
g. Leg Section. To lower the leg section (6001
only), press the LEG DOWN button (figure 3-9).
The leg section will go down to 105° below horizon-
tal. To raise the leg section, press the LEG UP
button. The leg section will go up to 20° above
horizontal.
