Page 21
WIRING DIAGRAM ST1919WC
- TERMINAL STRIPTS
- SUPPORT ARMSA
- RADIAL ARM ASSEMBLYRAA
- VERTICAL SUPPORT TUBEVST
- CRIMP CONNECTORS
- BRUSH BLOCK
- SLIP RING
L1-L3 - BULB
LEGEND
L3
L2L1
TS
BULB BULB
BULB
SA
SA
RAA
RAA
VST
VST
DIMMER
CONTROL
FUSE
3A
MAIN
POWER
SWITCH
TRANSFORMER
T-2 270W
INPUT
120VAC
DIMMER
CONTROL
FUSE
3A
TRANSFORMER
T-2 270W
