Page 20
WIRING DIAGRAM ST1919
- TERMINAL STRIPTS
- SUPPORT ARMSA
- RADIAL ARM ASSEMBLYRAA
- VERTICAL SUPPORT TUBEVST
- CRIMP CONNECTORS
- BRUSH BLOCK
- SLIP RING
L1-L3 - BULB
LEGEND
FUSEHOLDER
TRANSFORMER
L1
N
L2
P
L3
L2L1
TS
BULB BULB
BULB
DIMMER
CONTROL
DIMMER
SWITCH
SA
SA
RAA
RAA
VST
VST
120VAC
GROUND
5A FUSE (ST1919)3A FUSE (ST19)
