Item Part No. Description Qty.

Page 23

5-1. MOUNTING HUB AND RADIAL ARM ASSEMBLY

1 B4-342-69 COVER, junction box ..................................................................................................1

2 B4-030-43 SCREW, phillips, M3x8 ...............................................................................................3

3 B9-210-81 BOLT, allen, M5x25 ....................................................................................................4

4 B4-342-02 WASHER, flat, M5 ....................................................................................................... 4

5 B9-410-25 TRANSFORMER (ST19)............................................................................................. 1

B9-410-26 TRANSFORMER (ST1919) ........................................................................................1

6 B4-342-03 JUNCTION BOX ..........................................................................................................1

7 B4-342-04 STAND-OFF, junction box .......................................................................................... 4

8 B4-342-05 FUSEHOLDER ASSEMBLY .......................................................................................1

9 B4-341-01 MOUNTING HUB, ST19 ..............................................................................................1

B4-341-30 MOUNTING HUB, ST1919..........................................................................................1

10 B4-341-02 CEILING COVER ........................................................................................................1

11 B4-342-06 GROMMET ..................................................................................................................1

12 B9-210-21 FUSE, 250V, 3A (ST19) ..............................................................................................1

B9-210-22 FUSE, 250V, 5A (ST1919) ..........................................................................................1

13 B4-342-07 SNAP RING .................................................................................................................1

14 B4-342-08 SPACER .....................................................................................................................1

15 B4-342-09 BEARING ASSEMBLY, tapered roller ...................................................................... A/R

16 ----- RACE, bearing .......................................................................................................... A/R

17 B4-342-11 SCREW, phillips, M3x4 .............................................................................................A/R

18 B4-342-12 COVER, brush block .................................................................................................A/R

19 B4-342-13 BRUSH BLOCK ........................................................................................................ A/R

20 B4-342-14 SCREW, phillips, M3x8 (countersunk) .....................................................................A/R

21 B4-341-03 RADIAL ARM, 1000mm ............................................................................................A/R

B4-341-31 RADIAL ARM, 895mm .............................................................................................. A/R

22 B4-342-15 SLIP RING ................................................................................................................. A/R

23 B2-210-14 SCREW, set, slip ring ................................................................................................ A/R

24 B2-210-61 NUT, retainer...............................................................................................................1

25 B2-210-27 SCREW, set ................................................................................................................1

26 B2-210-56 SPACER .....................................................................................................................3

27 B4-341-04 RETAINER, hub cover ................................................................................................1

28 B4-342-16 WASHER, lock, M3 .....................................................................................................3

29 B4-342-17 SCREW, phillips, M3x16.............................................................................................3

30 B4-341-05 COVER, hub ...............................................................................................................1

NS B2-010-01 STANDARD MOUNTING PLATE ................................................................................1
