Item Part No. Description Qty.
Page 25
5-2. BALANCE MECHANISM AND YOKE ASSEMBLIES
1 B4-341-06 COVER, rubber ...........................................................................................................3
2 B4-242-23 SCREW, phillips, M5x12............................................................................................. 1
3 ----- RADIAL ARM ..............................................................................................................1
4 B4-341-07 VERTICAL SUPPORT TUBE ....................................................................................A/R
5 B9-310-06 SCREW, set ..............................................................................................................A/R
6 B3-210-05 BRUSH BLOCK ..........................................................................................................2
7 B3-310-13 MOUNT, brush block................................................................................................... 1
8 B4-242-11 SNAP RING .................................................................................................................1
9 B4-242-10 NUT .............................................................................................................................1
10 B1-010-37 SCREW, set, M4x8....................................................................................................A/R
11 B4-342-18 BUSHING ....................................................................................................................1
12 B4-341-08 SLEEVE, VST ..............................................................................................................1
13 B4-342-19 BUSHING ....................................................................................................................1
14 B4-342-20 WASHER, needle bearing (large) ..............................................................................2
15 B4-342-21 NEEDLE BEARING (large) .........................................................................................1
16 B9-210-28 SCREW, phillips, M4x8 ...............................................................................................4
17 B9-210-69 WASHER, flat, M4 .......................................................................................................4
18 B3-210-04 SLIP RING ...................................................................................................................2
19 B4-341-09 JOINT, upper knuckle .................................................................................................1
20 B4-242-20 PIN ..............................................................................................................................1
21 B4-242-19 BEARING .................................................................................................................... 2
22 B4-242-18 WASHER.....................................................................................................................2
23 B4-242-17 PIN, pivot .....................................................................................................................2
24 B3-210-32 WASHER, bearing ......................................................................................................4
25 B3-210-33 BEARING .................................................................................................................... 2
26 B9-210-81 SCREW, allen, M5x25 ................................................................................................2
27 B9-210-82 SCREW, set ................................................................................................................2
28 B4-342-22 BUSHING ....................................................................................................................2
29 B4-242-21 GUIDE, bearing, left ....................................................................................................1
B4-242-22 GUIDE, bearing, right ..................................................................................................1
30 B4-341-10 HOUSING, BOM, lower ...............................................................................................1
31 B4-242-23 SCREW, phillips, M4x12.............................................................................................8
32 B4-342-23 SHAFT, balance ..........................................................................................................1
33 B4-342-24 SPRING .......................................................................................................................1
34 B4-342-25 WASHER, needle bearing, (small) .............................................................................2
35 B4-342-26 NEEDLE BEARING, (small) ........................................................................................1
36 B4-342-27 BUSHING ....................................................................................................................1
37 B4-342-28 NUT, spring adjustment ..............................................................................................1
38 B9-210-28 SCREW, phillips, M4x8 ...............................................................................................3
39 B4-341-11 SUPPORT ARM ..........................................................................................................1
40 B3-420-08 COVER, adjustment ....................................................................................................1
41 B3-410-03 SCREW .......................................................................................................................2
42 B3-220-15 SCREW, phillips, M4x6 ...............................................................................................4
43 B4-342-29 MOUNT, slip ring.........................................................................................................1
44 B1-010-37 SCREW, set, M4x8....................................................................................................A/R
45 B4-242-28 NUT .............................................................................................................................1
46 B4-342-30 WASHER, wave ..........................................................................................................2
