Item Part No. Description Qty.

Page 29

5-3. YOKE ASSEMBLY

1 B4-342-17 SCREW, phillips, M3x16........................................................................................... A/R

2 B4-342-16 WASHER, lock, M3 ................................................................................................... A/R

3 B4-342-36 SCREW, phillips, M3x6 ............................................................................................. A/R

4 B4-340-01 CIRCUIT BOARD ......................................................................................................A/R

5 B4-342-37 STAND-OFF .............................................................................................................. A/R

6 B4-342-38 SPACER ...................................................................................................................A/R

7 B9-210-28 SCREW, phillips, M4x8 ............................................................................................. A/R

8 B9-210-69 WASHER, flat, M4 ..................................................................................................... A/R

9 ----- GROUND WIRE ..........................................................................................................1

10 B4-340-02 FRAME, inner support ................................................................................................1

11 B9-210-28 SCREW, phillips, M4x8 .............................................................................................A/R

12 B4-210-14 WASHER, lock, M4 ................................................................................................... A/R

13 B9-210-69 WASHER, flat, M4 ..................................................................................................... A/R

14 B4-342-29 MOUNT, slip ring.........................................................................................................1

15 B3-210-04 SLIP RING ...................................................................................................................1

16 B9-210-69 WASHER, flat, M4 .......................................................................................................2

17 B9-210-28 SCREW, M4x8 ............................................................................................................2

18 B1-010-37 SCREW, set,M4x8 ....................................................................................................A/R

19 B4-242-28 NUT .............................................................................................................................1

20 B4-342-30 WASHER, wave ..........................................................................................................2

21 B4-342-39 BEARING, needle (small) ...........................................................................................1

22 B4-342-32 SCREW, phillips, M4x4 ...............................................................................................1

23 B4-341-15 BEARING BODY .........................................................................................................1

24 B4-342-40 RUBBER TRIM............................................................................................................1

25 B4-342-33 BEARING, needle (large) ...........................................................................................1

26 B4-342-20 WASHER, needle bearing ..........................................................................................2

27 B4-342-21 BEARING, needle .......................................................................................................1

28 B4-341-16 YOKE, lighthead .........................................................................................................1

29 B4-342-35 SCREW, phillips, countersunk, M3x10 .......................................................................1

30 B4-342-41 SCREW, set .............................................................................................................. A/R

31 B3-210-05 BRUSH BLOCK ..........................................................................................................1

32 B4-341-14 COVER, yoke ..............................................................................................................1
