Item Part No. Description Qty.
Page 33
5-5. LIGHTHEAD ASSEMBLY
1 B4-340-05 TOP COVER, lighthead ..............................................................................................1
2 B1-210-34 TERMINAL STRIP ....................................................................................................... 1
3 B9-210-35 •SCREW, terminal strip cover ..................................................................................... 2
4 B1-210-35 •COVER, terminal strip................................................................................................1
5 B9-210-34 SCREW, terminal strip mounting ................................................................................2
6 B3-220-15 SCREW, bracket mounting, M4x6, phillips .................................................................2
7 B4-210-14 WASHER, lock, M4 .....................................................................................................2
8 B1-210-33 BRACKET, terminal strip mounting ............................................................................1
9 B4-342-46 COLLAR ...................................................................................................................... 1
10 B4-030-67 SCREW, set, M4x5......................................................................................................2
11 B1-410-51 NUT, hex .....................................................................................................................1
12 B4-342-47 SCREW, phillips, M4x22...........................................................................................A/R
13 B5-010-99 WASHER, flat, M4 ..................................................................................................... A/R
14 B3-220-16 SCREW, phillips, M4x8 .............................................................................................A/R
15 B4-210-14 WASHER, lock, M4 ................................................................................................... A/R
16 B5-010-99 WASHER, flat, M4 ..................................................................................................... A/R
17 B4-242-23 SCREW, phillips, M4x12.............................................................................................4
18 B9-410-08 WASHER, special .......................................................................................................4
19 B1-410-15 BAND ..........................................................................................................................2
20 B4-340-02 FRAME, inner support ................................................................................................1
21 B4-340-04 FACE, lighthead ..........................................................................................................1
22 B4-340-06 PLATE, inner ...............................................................................................................3
23 B4-340-07 PLATE, outer ...............................................................................................................3
24 B4-342-48 SCREW, phillips, M3x10.............................................................................................9
25 B4-340-08 CLIP, belt.....................................................................................................................2
26 B4-342-49 SCREW, phillips, countersunk, M3x12 .......................................................................2
27 B4-340-09 BELT ...........................................................................................................................1
28 B4-342-50 PIN, roll........................................................................................................................1
29 B1-410-50 PIN ..............................................................................................................................1
30 B4-340-10 HANDLE, engagement head assembly .....................................................................1
31 B4-342-51 SPRING .......................................................................................................................1
32 B4-340-11 LOCK, handle .............................................................................................................1
33 B1-210-50 HANDLE, sterilizable, positioning ..............................................................................1
To Next Page
