Skytron ST19 Series User Manual

Item Part No. Description Qty.
Page 35
5-6. ST19S - STAND MODEL ASSEMBLY
1 B9-210-28 SCREW, phillips, M4x8 ...............................................................................................2
2 B9-210-69 WASHER, flat, M4 ....................................................................................................... 2
3 B3-210-04 SLIP RING ................................................................................................................... 1
4 B4-342-52 MOUNT, slip ring......................................................................................................... 1
5 B4-341-17 SUPPORT ARM ..........................................................................................................1
6 B3-220-15 SCREW, phillips, M4x6 ...............................................................................................4
7 B5-011-03 SCREW, phillips, M4x10............................................................................................. 1
8 B4-342-53 SCREW, phillips, M4x9 ...............................................................................................4
9 B4-341-18 JOINT, upper knuckle .................................................................................................1
10 B4-341-19 PIN, pivot .....................................................................................................................2
11 B4-341-20 PIN ..............................................................................................................................1
12 B4-342-54 BEARING .................................................................................................................... 2
13 B4-342-55 SCREW, allen head, countersunk, M4x13 .................................................................2
14 B4-341-21 GUIDE, bearing, left ....................................................................................................1
B4-341-22 GUIDE, bearing, right ..................................................................................................1
15 B4-342-22 BUSHING ....................................................................................................................2
16 B4-341-29 HOUSING, BOM .......................................................................................................... 1
17 B4-342-56 SCREW, allen head, countersunk, M4x14 .................................................................8
18 B4-341-06 COVER, rubber ...........................................................................................................2
19 B4-341-23 SHAFT, balance ..........................................................................................................1
20 B4-341-24 SPRING .......................................................................................................................1
21 B4-342-25 WASHER, needle bearing ..........................................................................................2
22 B4-342-26 NEEDLE BEARING .....................................................................................................1
23 B4-342-27 BUSHING, nylon .........................................................................................................1
24 B4-342-28 NUT, spring adjustment ..............................................................................................1
25 B4-341-25 STAND POLE ..............................................................................................................1
26 B4-342-57 SCREW, phillips, M4x9 ...............................................................................................3
27 B4-242-45 CORD HOOK .............................................................................................................. 2
28 B5-011-03 SCREW, phillips, M4x10.............................................................................................4
29 A1-010-29-1 HANDLE, positioning..................................................................................................2
30 B4-342-58 CONNECTOR, male, 3-pin .........................................................................................1
31 B4-342-59 CONNECTOR, female, 3-pin ......................................................................................1
32 B4-211-03 BOLT, allen head, M5x10 ...........................................................................................2
33 B4-341-26 BASE ...........................................................................................................................1
34 B4-242-49 NUT .............................................................................................................................4
35 B4-341-32 COVER, base ..............................................................................................................4
36 B4-242-50 WASHER, lock ............................................................................................................4
37 B4-341-27 CASTER ......................................................................................................................4
38 B4-342-60 NUT, lock, M4 ..............................................................................................................4
39 B9-410-25 TRANSFORMER.........................................................................................................1
40 B4-341-28 HOUSING, transformer ...............................................................................................1
41 B5-010-99 WASHER, flat, M4 .......................................................................................................4
42 B5-011-03 SCREW, phillips, M4x10.............................................................................................4
43 B4-342-61 NUT, lock, M4 ..............................................................................................................1
44 B4-342-62 WASHER, star, M4 ......................................................................................................1
45 ----- GROUND WIRES ........................................................................................................2
46 B3-220-16 SCREW, phillips, M4x8 ...............................................................................................1
