Item Part No. Description Qty.

Page 39

5-7. WALL CONTROL ASSEMBLY

B9-410-01 WALL CONTROL, ST19WC .....................................................................................A/R

B9-410-02 WALL CONTROL, ST1919WC ................................................................................. A/R

1 B9-310-07 FLANGE, recess mount, single or dual ......................................................................1

2 B9-210-40 SCREW, flange mounting ........................................................................................... 8

3 B9-210-09 COVER, electrical access ........................................................................................... 1

4 B9-210-41 SCREW, cover mounting ............................................................................................2

5 B9-410-27 HOUSING, wall control, single or dual .......................................................................2

6 B9-410-29 PLATE, transformer mount, ST19WC .........................................................................1

B9-410-30 PLATE, transformer mount, ST1919WC .....................................................................1

7 B9-410-25 TRANSFORMER....................................................................................................... A/R

8 B9-410-35 CONNECTOR, 2 pin .................................................................................................A/R

9 B9-310-29 SCREW .....................................................................................................................A/R

10 B9-310-30 WASHER, lock .......................................................................................................... A/R

11 B9-310-31 WASHER, flat ............................................................................................................ A/R

12 B9-410-36 PANEL, wall control front, ST19WC ...........................................................................1

B9-410-37 PANEL, wall control front, ST1919WC ....................................................................... 1

13 B9-210-16 SWITCH, main power .................................................................................................1

14 B9-210-21 FUSE, 250V, 3A ........................................................................................................ A/R

15 B9-310-25 FUSE HOLDER .........................................................................................................A/R

16 B9-210-43 SCREW w/washers .....................................................................................................4

17 B9-210-20 KNOB, dimmer control .............................................................................................. A/R

18 B9-210-71 NUT, dimmer control .................................................................................................A/R

19 B9-210-70 WASHER...................................................................................................................A/R

20 B9-410-42 DIMMER CONTROL ASSEMBLY ............................................................................. A/R

21 B9-410-43 CONNECTOR, 2 pin .................................................................................................A/R
