Skywell ET5 2021 - Page 262

Vehicle specifications
252
9
King pin inclination
(°)
11.56


0.5

Caster angle (°)
5.7


0.5

Rear wheel camber
(°)
-1°
±
0.5°
Rear wheel toe
(mm)
0.21


5′
Main performance parameters
Rated power of
charger
6.6kW
DC-DC rated output
current
180A
DC-DC rated output
voltage
14
±
0.25V
DC-DC input
voltage range
240~450V
Motor
Model
TZ200XSJ
Maximum output
power
150kW
Rated power
65kW
Peak speed
15000r
Maximum output
torque
320 N∙ �
Rated torque
135N
∙ �
Weight
95.3Kg
