Driving preparation and setting
76
Chapter 6：Driving
preparation and setting
Instrument cluster assy
Instrument cluster assy displays the status, function, charging
status and other information of each system of the vehicle. When
using daily vehicles, you should always pay attention to the
information displayed by the instrument cluster assy to obtain the
real-time status of the vehicle. Instrument cluster assy will change
due to factors such as settings, function usage, vehicle
configuration, etc. The description in the figure below is for
reference only. Please refer to the actual vehicle for the display
interface.
12.3 IN instrument cluster assy(segment
code screen)
1． Gear information
2． Speed information
3． Mileage information
4． Recharge mileage
