93 0xFF
94 0xFF
95 0x3F
96 0x00
97 0xFF
98 0xFF
99 0xFF
100 0xFF
101 0xFF
102 0xFF
103 0xFF
104 0xFF
105 0xFF
106 0xBF
107 0xFF
108 0x7F
109 0xFF
110 0xFF
111 0xFF
112 0x7F
113 0xFF
114 0xFF
115 0xFF
116 0xFF
117 0xFF
118 0xFF
119 0xFF
120 0xFF
121 0xFF
122 0xFF
123 0xFF
Table 1. Register Write-Allowed Masks (Continued)
Address (Decimal) Mask (Hex)
*Note: See Figure 9 in the Si5338 data sheet for the correct usage of
registers 230, 241, and 246. These registers are not saved in the
register map or C code header file from ClockBuilder Pro.
