124 0xFF
125 0xFF
126 0xFF
127 0xFF
128 0xFF
129 0x0F
130 0x0F
131 0xFF
132 0xFF
133 0xFF
134 0xFF
135 0xFF
136 0xFF
137 0xFF
138 0xFF
139 0xFF
140 0xFF
141 0xFF
142 0xFF
143 0xFF
144 0xFF
145 0x00
146 0x00
147 0x00
148 0x00
149 0x00
150 0x00
151 0x00
152 0xFF
153 0xFF
154 0xFF
Table 1. Register Write-Allowed Masks (Continued)
Address (Decimal) Mask (Hex)
*Note: See Figure 9 in the Si5338 data sheet for the correct usage of
registers 230, 241, and 246. These registers are not saved in the
register map or C code header file from ClockBuilder Pro.
