155 0xFF
156 0xFF
157 0xFF
158 0x0F
159 0x0F
160 0xFF
161 0xFF
162 0xFF
163 0xFF
164 0xFF
165 0xFF
166 0xFF
167 0xFF
168 0xFF
169 0xFF
170 0xFF
171 0xFF
172 0xFF
173 0xFF
174 0xFF
175 0xFF
176 0xFF
177 0xFF
178 0xFF
179 0xFF
180 0xFF
181 0x0F
182 0xFF
183 0xFF
184 0xFF
185 0xFF
Table 1. Register Write-Allowed Masks (Continued)
Address (Decimal) Mask (Hex)
*Note: See Figure 9 in the Si5338 data sheet for the correct usage of
registers 230, 241, and 246. These registers are not saved in the
register map or C code header file from ClockBuilder Pro.
