58 MS0_P2[29:22]
59 MS0_P3[7:0]
60 MS0_P3[15:8]
61 MS0_P3[23:16]
62 MS0_P3[29:24]
63 MS1_FIDCT[1:0] MS1_FIDDIS MS1_SSMODE[1:0] MS1_PHIDCT[1:0]
64 MS1_P1[7:0]
65 MS1_P1[15:8]
66 MS1_P2[5:0] MS1_P1[17:16]
67 MS1_P2[13:6]
68 MS1_P2[21:14]
69 MS1_P2[29:22]
70 MS1_P3[7:0]
71 MS1_P3[15:8]
72 MS1_P3[23:16]
73 MS1_P3[29:24]
74 MS2_FRCTL[1:0] MS2_FIDDIS MS2_SSMODE[1:0] MS2_PHIDCT[1:0]
75 MS2_P1[7:0]
76 MS2_P1[15:8]
77 MS2_P2[5:0] MS2_P1[17:16]
78 MS2_P2[13:6]
79 MS2_P2[21:14]
80 MS2_P2[29:22]
81 MS2_P3[7:0]
82 MS2_P3[15:8]
83 MS2_P3[23:16]
84 MS2_P3[29:24]
85 MS3_FIDCTL[1:0] MS3_FIDDIS MS3_SSMODE[1:0] MS3_PHIDCTL[1:0]
86 MS3_P1[7:0]
87 MS3_P1[15:8]
88 MS3_P2[5:0] MS3_P1DIV[17:16]
89 MS3_P2[13:6]
90 MS3_P2[21:14]
91 MS3_P2[29:22]
92 MS3_P3[7:0]
93 MS3_P3[15:8]
94 MS3_P3[23:16]
95 MS3_P3[29:24]
Table 2. Register Summary (Continued)
Register 7 6 5 4 3 2 1 0
