97 MSN_P1[7:0]
98 MSN_P1[15:8]
99 MSN_P2[5:0] MSN_P1[17:16]
100 MSN_P2[13:6]
101 MSN_P2[21:14]
102 MSN_P2[29:22]
103 MSN_P3[7:0]
104 MSN_P3[15:8]
105 MSN_P3[23:16]
106 MSN_P3[29:24]
107 MS0_PHOFF[7:0]
108 MS0_PHOFF[14:8]
109 MS0_PHSTEP[7:0]
110 CLK0_DISST[1:0] MS0_PHSTEP[13:8]
111 MS1_PHOFF[7:0]
112 MS1_PHOFF[14:8]
113 MS1_PHSTEP[7:0]
114 CLK1_DISST[1:0] MS1_PHSTEP[13:8]
115 MS2_PHOFF[7:0]
116 MS2_PHOFF[14:8]
117 MS2_PHSTEP[7:0]
118 CLK2_DISST[1:0] MS2_PHSTEP[13:8]
119 MS3_PHOFF[7:0]
120 MS3_PHOFF[14:8]
121 MS3_PHSTEP[7:0]
122 CLK3_DISST[1:0] MS3_PHSTEP[13:8]
123 MS0_FIDP1[7:0]
124 MS0_FIDP1[15:8]
125 MS0_FIDP1[23:16]
126 MS0_FIDP1[31:24]
127 MS0_FIDP1[39:32]
128 MS0_FIDP1[47:40]
129 MS0_FIDP1[51:48]
130 MS0_FIDP2[51:48]
131 MS0_FIDP2[47:40]
132 MS0_FIDP2[39:32]
133 MS0_FIDP2[31:24]
134 MS0_FIDP2[23:16]
Table 2. Register Summary (Continued)
Register 7 6 5 4 3 2 1 0
