135 MS0_FIDP2[15:8]
136 MS0_FIDP2[7:0]
137 MS0_FIDP3[7:0]
138 MS0_FIDP3[15:8]
139 MS0_FIDP3[23:16]
140 MS0_FIDP3[31:24]
141 MS0_FIDP3[39:32]
142 MS0_FIDP3[47:40]
143 MS0_FIDP3[55:48]
144 MS0_ALL MS0_FIDP3[62:56]
152 MS1_FIDP1[7:0]
153 MS1_FIDP1[15:8]
154 MS1_FIDP1[23:16]
155 MS1_FIDP1[31:24]
156 MS1_FIDP1[39:32]
157 MS1_FIDP1[47:40]
158 MS1_FIDP1[51:48]
159 MS1_FIDP2[51:48]
160 MS1_FIDP2[47:40]
161 MS1_FIDP2[39:32]
162 MS1_FIDP2[31:24]
163 MS1_FIDP2[23:16]
164 MS1_FIDP2[15:8]
165 MS1_FIDP2[7:0]
166 MS1_FIDP3[7:0]
167 MS1_FIDP3[15:8]
168 MS1_FIDP3[23:16]
169 MS1_FIDP3[31:24]
170 MS1_FIDP3[39:32]
171 MS1_FIDP3[47:40]
172 MS1_FIDP3[55:48]
173 MS1_FIDP3[62:56]
174 MS2_FIDP1[7:0]
175 MS2_FIDP1[15:8]
176 MS2_FIDP1[23:16]
177 MS2_FIDP1[31:24]
178 MS2_FIDP1[39:32]
179 MS2_FIDP1[47:40]
Table 2. Register Summary (Continued)
Register 7 6 5 4 3 2 1 0
