Register 3.
BitD7D6D5D4D3D2 D1 D0
Name
Dev_Config3[7:3] Dev_Config3
Type RR
Bit Name Function
7:3
Dev_Config3[7:3]
Bits 7:3 represent the device grade: 1 through 24 = A thorugh Z.
See "10.6.1. Example Part Number for Device ID Registers" on page 55 for complete
part number example.
2:1
Reserved
0
Dev_Config3[0]
Bit 0 represents bit 16 of the NVM code assigned by Skyworks Solutions: 00000
through 99999.
See "10.6.1. Example Part Number for Device ID Registers" on page 55 for complete
part number example.
Register 4.
BitD7D6D5D4D3D2 D1 D0
Name
Dev_Config4[7:0]
Type R
Bit Name Function
7:0
Dev_Config4[7:0]
Bits 7:0 represent bits 15:8 of the NVM code assigned by Skyworks Solutions: 00000
through 99999.
See "10.6.1. Example Part Number for Device ID Registers" on page 55 for complete
part number example.
