Reset value = xxxx xxxx
10.6.1. Example Part Number for Device ID Registers
Device ID register contents for an example part number Si5338N-B12345-GM:
Register 0[2:0] = 001
Register 2 = 66h = 0110 0110
Register 3 = 72h = 0111 0010
Register 4 = 30h = 0011 0000
Register 5 = 39h = 0011 1001
REVID = B
Dev_Config2[5:0] = 10 0110 = 38 (base part number).
Dev_Config3[7:3] = 0 1110 = 14 = N (device grade).
Dev_Config3[0], Dev_Config4[7:0], Dev_Config5[7:0] = 0 0011 0000 0011 1001 = 12345 (NVM code number).
Please refer to the Si5338 data sheet's Ordering Guide section for detailed information about ordering part
numbers.
Register 5.
BitD7D6D5D4D3D2 D1 D0
Name
Dev_Config5[7:0]
Type R
Bit Name Function
7:0 Dev_Config5[7:0]
Bits 7:0 represent bits 7:0 of the NVM code assigned by Skyworks Solutions: 00000
through 99999.
See "10.6.1. Example Part Number for Device ID Registers" on page 55 for complete
part number example.
