REPLACING THE SEAT WHEELS
TOOLS NEEDED:
5MM ALLEN KEY
13MM WRENCH
PHILLIPS SCREWDRIVER
1. Remove screws from the rear top rail endcaps and
remove endcaps.
2. Slide the seat off. Using the 5mm Allen key and 13mm
wrench, remove the nut and bolt.
3. Take the old wheel off and put the new one on. Make
sure to put washer on one side of the bolt and the
spacer on the other.
The easiest way to do this is to:
-put the bolt partially through
-put on the washer
-put the wheel on
-partially slide bolt through the wheel (to hold wheel)
-insert the spacer
-push bolt through
4. Screw nut on and tighten until the bolt has passed
the lock nut thread. In order to ensure the wheel spins
freely, be sure not to overtighten.
5. Repeat above steps until all the wheels have been
replaced.
6. Put the seat back on the top rail. Make sure the indent
is towards the back of the machine.
7. Replace the end caps and screws.
