20
3. Loop the new foot strap through with the buckle part
towards the middle of the footboard. Note the hole in
the foot strap, line up the hole in the strap with the
screw hole in the footboard.
4. Insert the screw through the footboard and hole in the
foot strap.
REQUIRED TOOLS:
7MM WRENCH
PHILIPS SCREWDRIVER
1. Using the 7mm wrench, locate the small nut on the back
of the footboard. Hold the nut with the wrench. Using
the screwdriver, unscrew the middle inside bolt.
2. Remove the screw, bolt and old strap. Place screw
nearby for reuse.
FOOT STRAP REPLACEMENT
