REPLACING THE FLYWHEEL
REQUIRED TOOLS:
17 MM WRENCH (2)
PHILIPS HEAD SCREWDRIVER
MALLET
1. Take screws (4) out of the Flywheel Cover, Remove Cover
2. Using both 17 mm wrenches, loosen the flywheel bolt.
3. Loosen flywheel nut, take off spacer and nut. and remove
flywheel. If the flywheel won’t come off, put the nut back
on the end of the shaft and tap the nut with the mallet.
This will loosen the flywheel, and allow you to remove it.
4. Replace with new flywheel. You may need to tap on the
opposite side of the shaft for it to slide on all the way.
Take the spacer and nut and put back on the shaft.
5. Tighten bolts on both sides of the shaft. Take a few
strokes to check that is not too tight. If it is too tight,
the chain won’t recoil properly.
6. Put flywheel cover back on and put the screws back in.
