5
REPLACING THE IDLER SPROCKET ASSEMBLY
REQUIRED TOOLS:
(2) 4MM ALLEN KEYS
3MM ALLEN KEY
VICE GRIPS OR PLIERS
CLOTH
1. To release bungee pressure, stand the machine up and
unclip bungees from the axle. Clip on the safety bungee
bracket (or tie off so they don’t slip into the machine).
2. Use 4mm Allen wrench to remove plastic cover (4 bolts).
3. Take 3mm Allen wrench (you may need to tap with a
mallet) and loosen the bolts on the monitor cover and
the front cover. Be careful not to strip - turn slowly with
pressure or apply WD-40/ Liquid Wrench.
To Next Page
