REMOVING/MOUNTING THE SLIDING GUIDES (if any)
If present, there are sliding guides, left and right, that are therefore not
interchangeable, on both sides of the oven.
Proceed as follows to remove the sliding element from the lateral guide:
release the lateral guide from the oven together with the sliding element, as
indicated in the previous paragraph.
Place the guide on a flat surface. Now exert some pressure from top down near the
couplings in the sliding element (fig. 1 step 1). When the couplings below come
out of the rod of the lateral guide, the sliding element has been released and
can be removed. (fig. 1 step 2).
fig. 1
To reposition the sliding guide, position the upper hooks on the special rods of
the lateral guide. Always make sure that the sliding element is able to slide by
moving in towards the outside of the oven. Now press the sliding element
downwards (fig. 2 step 1) so that it is firmly coupled onto the lower rods (fig2 step
2).
fig. 2
