Do not use any sharp-edged objects to
prise out the cover from the centre console.
Otherwise, the cover or the centre console
could be damaged.
X
Apply the parking brake.
X
Open the drawer on the front-passenger
side.
X
Prise out cover : on the centre console
from bottom edge ; using with a flat,
blunt object.
X
Pull cover : in the direction of the arrow.
X
Pull yellow release = behind the trim up
and simultaneously press release but-
ton ? on the selector lever.
X
Shift the gear selector lever to position i
or j.
Replacing the bulbs
Please note
G
WARNING
Bulbs, lamps and plug connectors can
become very hot during use. When replac-
ing a bulb, you could burn yourself on
these components. There is a risk of injury.
Allow these components to cool down
before replacing the bulb.
Observe the following rules when replacing
bulbs:
R
Only replace bulbs when the engine is
switched off.
R
Do not use bulbs that have been dropped or
show signs of visible damage, e.g.
scratches.
R
Do not touch the glass bulb with your bare
hands.
R
Only use bulbs in enclosed lamps designed
for that purpose.
R
Only fit spare bulbs of the same type and
with a specified voltage.
R
Do not allow bulbs to come into contact
with moisture.
R
Have LEDs changed at qualified specialist
workshops only.
Change only the bulbs described below your-
self in accordance with the specified bulb
types.
Replacing front bulbs
Changing dipped-beam and main-beam
headlamps
X
Switch off the lights.
X
Open the service cover.
X
Remove cover :.
X
Pull out the connector.
X
Press retainer ; inwards and to the left.
X
Pull the bulb out.
Replacing the bulbs
179
>> Dealing with accidents and breakdowns.
