Removing the tail lamp cover
X
Switch off the lights.
X
Open the tailgate.
X
Loosen screws :.
X
Remove the tail lamp.
X
Carefully insert a flat tool under the plas-
tic hanger on the tail lamp.
X
Lift the connector and remove it.
Replacing a faulty tail lamp bulb
:
Rear lamp/brake lamp (vehicles without
partial LEDs)
;
Turn signals
=
Reversing lamp
?
Rear fog lamp (vehicles without partial
LEDs)
X
Release four tabs A on the bulb holder.
X
Remove the bulb holder.
X
Pull the faulty bulb out.
X
Insert the new bulb.
X
Refit the bulb holder.
X
Insert the connector.
X
Insert the tail lamp until you hear it
engage.
X
Tighten the screws on the tail lamp.
Replacing the licence plate lighting
X
Insert a flat tool into recess :.
X
Remove the cover from the licence plate
lamp.
X
Remove the bulb from the holder.
X
Insert the new bulb into the holder.
X
Insert the lamp lens into the licence plate
lamp.
Replacing the interior lighting
X
Insert a flat tool into the recess.
X
Prise out lamp lens :.
X
Remove the bulb from the holder.
X
Insert the new bulb into the holder.
X
Refit the lamp lens.
Changing fuses
Please note
G
WARNING
If you manipulate, bridge or replace a
faulty fuse with a fuse of a higher amper-
Changing fuses
181
