Charging cable
Charging the battery at a charging station
or wall box
Nominal voltage max. 400 V AC,
max. 3-phase
Nominal frequency 50 Hz / 60 Hz
Nominal current max. 32 A
Charge output from 4.6 kW to
22 kW
System of protection IP44 (inserted),
IP24 (not inser-
ted)
Outside temperature
Observe the notes on
maintaining the high-
voltage bat-
tery(Y page 79)
-40 † to +50 †
Standards IEC 61851-1,
IEC 62196-1,
IEC 62186-2
Interface Type 2 to Type
2
Also observe the identification plate on the
charging cable connector.
Service products
Please note
Also observe the information in the section
"Checking and refilling service products"
(Y page 156).
Vehicle components and their respective
service products must match. Therefore, only
use products tested and approved by
Mercedes-Benz.
Information on service products
The following table lists all technical data
for the service products of the vehicle. Fur-
ther information on service products: http://
bevo.mercedes-benz.com and in any smart
centre.
Service prod-
ucts
Specifications
Corrosion
inhibitor/
antifreeze
(Y page 156)
Recommended: G40
Windscreen
washer fluid
(Y page 157)
Temperatures above
freezing point: mixing
ratio of 1:100
MB SummerFit to water.
Temperatures below
freezing point: for the cor-
rect mixing ratio of
MB WinterFit and water,
please observe the infor-
mation on the antifreeze
container.
Bulb types
The following table lists the correct bulb
types of the vehicle:
Bulb Type
Dipped-beam/main-beam
headlamps
H4 60/55 W
Front foglamps H 16
Turn signals PY 21 W
Side turn signal lamps WY 5 W
Licence plate lighting W 5 W
Interior lighting W 5 W
Tail lamps
Bulb Type
Tail lamp and brake lamp P21 5 W
Rear foglamp P21 W
Reversing lamp W 16 W
Turn signals PY 21 W
Bulb types
209
