To make sure the heating or air
conditioning with climate control works
properly, please observe the following:
R
Keep the air intake grill free from
deposits, e.g. ice or snow, to ensure that
fresh air can flow freely into the vehicle
interior.
R
Do not obstruct air vents or ventilation
grilles in the vehicle interior.
i
For draft-free ventilation, move the
sliders for the center air vents and side
air vents to the middle position.
Center air vents
:
Left center air vent, adjustable
;
Right center air vent, adjustable
X
Adjusting: Turn slider : or ; to the
left, right, up, or down.
X
Opening: Turn slider : or ; inwards
towards the center console.
X
Closing: Turn slider : or ; fully
outwards towards the side window.
Side air vents
Side air vents on driver’s side illustrated as
example
:
Left side air vent, adjustable
;
Left side defroster air vent, fixed
X
Adjusting: Turn slider : to the left,
right, up, or down.
X
Opening: Turn slider : inwards towards
the center console.
X
Closing: Turn slider : fully outwards
towards the side window.
Adjusting air distribution
Symbol Function
z
Directs air to the windshield
and side windows
O
Directs air to the footwells
and air distribution is
reduced at the center and side
air vents
P
Directs air through the center
and side air vents
i
You can also turn the air distribution
control to a position between two
symbols.
Control panel (Y page 97).
98
Air conditioning with climate control
>> Controls.
