X
Insert hooks A on the back of service
flap = into openings B.
Remounting
X
Lift service flap = out of openings B.
X
Insert left and right links D of service
flap = under links C on the fender.
X
Insert both tabs E on the back of service
flap = completely into openings F.
X
Push service flap = down in direction
of arrow G.
X
First push both levers ; inward and then
to the rear.
X
Press both levers ; into the radiator
grille until they engage.
Coolant
G
WARNING
The cooling system is pressurized.
Therefore, do not unscrew the cap before
the drive system has cooled down. Wait for
Front compartment
119
>> Operation.
