tensioning spring could crack the
windshield.
Do not allow the wiper arms to contact the
windshield glass without a wiper blade
inserted.
We recommend that you have this work
carried out at an authorized electric
drive smart center.
To ensure proper visibility
R
it is vital that you have wiper blades that
are in perfect shape
R
clean the wiper blades regularly with a
cleaning agent
R
remove any tough dirt stains with a
sponge or brush
Windshield wiper blades
!
Do not pull on the wiper blade inserts.
They could tear.
Removing
X
Remove the key from the starter switch.
X
Fold wiper arm ? away from the
windshield until it snaps into place.
X
Press on retaining springs ; on both
sides of wiper blade :.
X
Fold wiper blade : away from wiper
arm ? in direction of arrow =.
X
Detach wiper blade : in direction of
arrow A.
Installing
X
With guide tab A sliding into opening
B, attach new wiper blade : onto the
wiper arm.
X
Fold wiper blade : towards the wiper
arm in direction of arrow =.
Retaining springs ; must audibly
engage in attachment ?.
X
Check whether wiper blade : is securely
fastened.
X
Fold the wiper arm backward to rest on
the windshield.
Make sure to hold on to the wiper when
folding it back.
!
Make sure the wiper blades are properly
installed. Improperly installed wiper
blades may cause windshield damage.
Rear window wiper blade
Replacing wiper blades
179
>> Practical hints.
