SMART fortwo cabriolet User Manual

No. Accessory/Component Amperage Color
E
CPC, shifter, brake force booster vacuum
pump
7.5 A Brown
F
Coolant pumps 1 and 2, high-voltage battery 15 A Blue
G
ESP
®
control unit
25 A Neutral
H
Exterior lamp switch, turn signal lamp
switch, cockpit switch module, on-board
diagnostics socket, exterior rear view
mirror heating, anti-theft warning system,
rain-light sensor, charge level and power
gauges, central locking system, instrument
cluster, Tire Pressure Monitoring System
(TPMS), brake and turn signal lamps (left and
right)
10 A Red
I
— — —
J
— — —
K
Safety circuit high-voltage battery 15 A Blue
L
— — —
M
Rear window wiper (coupé only) 15 A Blue
N
ESP
®
control unit, EPS control unit, restraint
systems
10 A Red
O
Electric drive components 7.5 A Brown
P
Air conditioningsystem, exterior rear view
mirror adjustment,washer pump, audio, seat
heating, wiper switch, cruise control, soft
top switch (cabriolet only)
10 A Red
Q
Auxiliary power outlet 15 A Blue
R
Left low‑beam headlamp 7.5 A Brown
S
Right low‑beam headlamp 7.5 A Brown
T
Backup lamp 15 A Blue
U
Right high‑beam headlamp 7.5 A Brown
V
Left high‑beam headlamp 7.5 A Brown
W
Electric drive components 7.5 A Brown
X
Rear window defroster 40 A Orange
Y
Soft top (cabriolet only) 30 A Green
202
Fuses
>> Practical hints.
