7.3.2 T-netx Jumper Block 2
Jumper Block J2 is located in the upper right-hand corner of the T-netx CPU/Reader interface
board. This block is factory set with the top jumper installed and the bottom jumper removed.
These settings should not be altered
7.3.3 T-netx Switches SW2, SW3, SW4 and SW5 – Not Used
Theses switches are either not used or set through software configuration only. Their settings on
the board are not recognized.
7.3.4 T-netx Power Select
The power select jumper is located on the lower left-hand side of the T-netx CPU/Reader
interface board. The power select jumper is factory set for the specific T-netx model. Do not
change the factory setting.
.
