SMARTEYE Netx Ethernet IP Control Unit User Manual Page A-1
Filename: netx IP Platform User Manual R0 .doc
…
In Control
A
M
Appendix A S-netx SP4002 Drawings
Sender/Receiver Cable Details for Local Mounting Applications – SP1054/01-417
This drawing shows the wiring details for a locally mounted reader.
Sender/Receiver Cable Details for Remote Mount Applications –SP1054/01-418
This drawing shows the wiring details for a remotely mounted reader using a customer supplied
junction box.
S-netx Installation Details No-Power over Ethernet– SP4002/01-420
This drawing shows the mounting dimensions of the S-netx.
S-netx Connection Wiring Details No-Power over Ethernet– SP4002/01-410
This drawing shows the location and wiring details for the Ethernet and power connections.
S-netx Installation Details Power over Ethernet – SP4002/02-420
This drawing shows the mounting dimensions of the S-netx.
S-netx Connection Wiring Details Power over Ethernet – SP4002/02-410
This drawing shows the location and wiring details for the Ethernet connection.
S-netx Auxiliary and Communication Port Wiring Details – SP4002/01-411
This drawing shows the wiring details for the auxiliary and communication port for all S-netx
models.
