14.0 Error Messages
Error Code Meaning
00 Control Unit just powered up
01 Unrecognizable label, too much data obtained.
04 Unrecognizable label, front and back bits = 0.
05 Unrecognizable label, front and back bits = 1.
Note: Errors 01, 04, and 05 can be the result of parts of a carrier breaking the photoeye beams.
06 Unrecognizable label, incorrect parity. Check label for
obstructions.
10 Unrecognizable host message received.
15 Unrecognizable label, incorrect Hamming code. Check label for
obstructions.
16 Unrecognizable label, more than 5 leading zeros.
17 Host message received w/o <cr> terminator.
19 Overload of input data from readers.
20 Checksum error in host message received.
30-39 Unrecognizable label, incorrect number of data bits. LSD (least
significant digit) of error is the LSD of the number of data bits in
the label read.
Errors 91 through 99 are detected during diagnostic:
91 Photoeye A, insufficient number of transitions in time allowed.
92 Photoeye B, insufficient number of transitions in time allowed.
93 Photoeyes A and B, insufficient number of transitions in time allowed.
94 Photoeye C, insufficient number of transitions in time allowed.
95 Photoeyes A and C, insufficient number of transitions in time allowed.
96 Photoeyes B and C, insufficient number of transitions in time allowed.
Note: Errors 91, 92, and 94 indicate that a photoeye is not transitioning while the other two
photoeyes are. Check reader height, photoeye operation, and reader wiring.
99 Diagnostic attempt aborted, acceptable hole pattern not found, probably due to
label speed variation. E99 is sent to the control system if diagnostic mode is
enabled in the setup or an ‘L’ or ‘C’ command has been sent to the control
unit.
